Aluminum Formwork Form Flat Tie

The EVERSTAR Aluminum Formwork Flat Tie is a high-strength steel wall tie designed to secure and accurately space opposing aluminum form panels during concrete placement. Although it is used with aluminum formwork, the tie itself is manufactured from selected steel to provide the required tensile performance.

The product shown features a narrow central tie section, enlarged rectangular end plates, round pin holes and controlled breakback details near both ends. The round holes connect to compatible form pins and wedges, while the fixed tie length determines the distance between the opposing form faces and therefore the finished concrete-wall thickness.

Full-size and nominal-size versions can be manufactured according to the customer's formwork system. Overall length, hole-to-hole dimension, form-face distance, tie width, thickness, pin-hole diameter, breakback position, material performance and packaging are produced from approved drawings or physical samples.

Inquire Now Next Products

Specifications

Item	Specification
Product name	Aluminum Formwork Steel Flat Wall Tie
Alternative names	Full Wall Tie, Nominal Wall Tie, Aluminum Form Tie
Brand	EVERSTAR
Material	Selected high-strength carbon steel
Structure	Narrow center section with enlarged round-hole connection ends
Common wall-size references	6, 8, 9, 10 and 12 in
Other wall sizes	Custom sizes according to approved drawings or samples
Common thickness reference	Approximately 1.8–3.0 mm
Tie width	According to approved design
End connection	Round pin hole at each end
Breakback detail	Controlled notches or reduced sections as specified
Matching hardware	Round-head or flat-head form pins with straight or curved wedges
Manufacturing process	Precision blanking or cutting, hole punching, notch forming, deburring and inspection
Surface condition	Natural metallic steel appearance or according to approved sample
Mechanical performance	According to approved design and EVERSTAR test report
Reusability	Normally remains embedded in concrete; exposed ends are removed according to design
Marking	Size, batch code or customer marking available
Packaging	Bundles, cartons, wooden cases or export pallets
Service	OEM, ODM, drawing-based and sample-based production

Features

High-strength carbon-steel construction

Accurate concrete wall-thickness control

Strong narrow central tie section

Enlarged end plates for stable connection

Precision-punched round pin holes

Fast pin-and-wedge installation

Controlled breakback sections

Full-size and nominal-size options

Custom length, thickness, holes and packaging available

Applications

Aluminum Formwork Assembly and Installation

Aluminum Formwork Connections and Accessories

Aluminum Formwork for Concrete Wall Construction

Aluminum Formwork Staircase System

Aluminum Wall Formwork Installation

Full-Scale Aluminum Formwork Assembly

Heavy-Duty Steel Formwork System

Integrated Wall and Slab Aluminum Formwork System

Packaging and Customization

Parameter	Details
OEM & ODM	OEM and customized specifications are welcome.
Product	Construction Materials / Agriculture / Packaging / Industrial
Category	Hardware
Supply Ability	In Stock
MOQ	Negotiable
Delivery Time	Usually 7–20 days depending on order quantity.
Special Requirements	Customized diameter, roll weight, packaging, labels, and logos are available according to customer requirements.

Packaging

Coil

Carton packing available

Plastic film inside

Pallet packing available

Woven bag outside

Customized packaging accepted
